Singlemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH Cable

  • 1
  • 2
  • 3

Place of Origin : Shenzhen , China

Brand Name : CY COM

Certification : ISO9001:2015 , RoHS

MOQ : 100

Packaging Details : PE bag

Delivery Time : 3-15 days

Payment Terms : L/C,T/T,Western Union payments for offline orders.

Supply Ability : 1 million connector / month

Product Name : Fiber Optic Patch Cord

Type : Singlemode Or Multimode

Ferrule End-face : UPC,APC

Cable Diameter : φ3.0,φ2.0,φ0.9

Cable Length : 1M, 3M, 5M, Customized

Core : Simplex, Duplex

Contact Now

Singlemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH Cable




Features:

  • In-line with Telcordia GR-326-CORE standard
  • Low insertion loss, high return loss, high reliability
  • Good repeatability, interchangeability
  • Any diameter of fiber can be chose, 0.9, 2, 3mm ,10g fiber, low smoke and zero halogen can be chosen


Application:

  • Fiber-optic communication system
  • Fiber-optic data transmission
  • LAN, CATV
  • Fiber-optic testing system


Material of patch cord:

  • Dust caps: LDPE, transparent (RoHS)
  • Plug housing: PBT, UPC/blue, APC/green, MM/beige (RoHS)
  • Inner frame: PBT, white (RoHS)
  • Ferrule: zirconium oxide ceramic material, white (RoHS)
  • Ferrule’s handle: copper (C3602), nickelage (RoHS)
  • Mechanical spring: stainless steel (RoHS)
  • Locating snap ring: copper alloy (HPD59-1), nickelage (RoHS)
  • Snap ring: aluminium alloy 6063 (RoHS)
  • Ring: copper alloy (HPD62), nickelage (RoHS)
  • Boot: nylon or PBT, UPC/blue, APC/green, MM/beige
  • Cable: SM/OM1/OM2/OM3/OM4, PVC/LSZH/OFNP

Specification:


ItemUnitFC,SC,LCST,MUMT-RJ, MPOE2000
SMMMSMMMSMMMSM
PCUPCAPCPCUPCPCPCPCUPCPCPCUPC
Insertion loss(typical)dB≤0.3≤0.2≤0.3≤0.2≤0.3≤0.2≤0.2≤0.3≤0.2≤0.2≤0.3≤0.3
Return lossdB≥45≥50≥60≥30≥45≥50≥30≥45≥50≥35≥55≥75
Operating wavelengthnm1310,15101310,15101310,15101310,1510
ExchengeabilitydB≤0.2≤0.2≤0.2≤0.2
VibrationdB≤0.2≤0.2≤0.2≤0.2
Operating temperature°C-40~75-40~75-40~75-40~75
Storage temperature°C-45~85-45~85-45~85-45~85
Cable Diametermmφ3.0,φ2.0,φ0.9φ3.0,φ2.0,φ0.9φ3.0,φ2.0,φ0.9φ3.0,φ2.0,φ0.9


Order information:

  • For example: SC/UPC-SC/UPC-SM-SX-2.0-5M-LSZH Armored patch cord
  • Type: SX/DX optional
  • Ferrule type: APC/PC
  • Diameter: 0.9, 2.0, 3.0mm
  • Length: 1, 2, 3 to 120m
  • Fiber: SM/OM1/OM2/OM3/OM4
  • Material of jacket: PVC/LSZH/OFNP
  •


Singlemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH CableSinglemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH CableSinglemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH CableSinglemode Duplex 3.0 Optical Fiber Patch Cord SC/APC to SC/APC with LSZH Cable
