SC / APC Single mode, G657B3 fiber, LSZH, Fiber Optic Patch Cord

Place of Origin : Shenzhen , China

Brand Name : CY COM

MOQ : 20

Packaging Details : PE bag

Delivery Time : 3-15 days

Payment Terms : L/C,T/T,Western Union payments for offline orders.

Supply Ability : 1 million connector / month

Certification : ISO9001:2015 , RoHS

Cable color : White, or as your requirements

Cable : G,657B3, G652D, or as your requirements

Cable type : PVC, LSZH, OM3, OFNR, OFNP, Armoured

Cable diameter : 0.9mm, 2.0mm, 3.0mm

Contact Now

SC / APC Single mode, G657B3 fiber, LSZH, Fiber Optic Patch Cord

SC/APC-SC/APC-SM-SX-3.0mm-3M, white color

SC connector stands for Subscriber Connector- a general purpose push/pull style connector. It is a square, snap-in connector latches with a simple push-pull motion and is keyed.

Features:

High return loss
Low insterion loss
Telcordia style boots
Compiance with TIA/IEA, IEC, Rohs



Application:

1,FTTH , CATV, LAN, MAN, WAN, Test &Measuremen
2,Video transmission , Data transmission
3,Active Device Termination
4,Premise Installations
5,Telecommunication and Data processing Networks
6, Industrial, medical & military
7,Systems Integration for Long Haul, Metro and Access Network
Specification APC(Standard) UPC(Standard)
IL (Insertion Loss) ≤0.3dB ≤0.2dB
RL (Return Loss) ≥50dB ≥55dB
Operating Temperature -40℃ to 75℃
Durability ≤0.1dBtypical change, 500matings
Available Wavelength SM=1310&1550nm

Ordering Information:

  1. Connector type: FC, SC,   LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
  2. Ferrule End-face: PC, UPC, APC
  3. Core Type: Single mode(SM: 9/125um), Multimode(MM: 50/125um or 62.5/125um)
  4. Core quantity: Simplex(SX), Duplex(DX)
  5. Cable diameter: 0.9mm, 2.0mm, 3.0mm
  6. Cable Length: 1M, 2M, 3M....
  7. Cable type: PVC, LSZH, OM3, OFNR, OFNP, Armoured...
  8. Color: Yellow, Orange, Green, Red, Blue.....
